Manpa 3" Multi Cutter MASTER KIT MP21-3-M (Includes 2 Extension tools and additional 4"- 8mm Circular Cutter blade)
€379.00
Highly Recommended for Pro Carvers.
3" & 4" Blades can be used.
Includes :
• One - 3" Circular cutter 8mm
• One - 4" Circular cutter 8mm
• 200 - 270 - 348 Extension
Features :
• Smooth Carving with Sharp Carbide
• Detail & Sculpting Performance
• Vibration Reduction
*Angle grinder is not included
Please check your "Spindle size" and "angle grinder".
Multi Cutter – Master Kit Contents
① Multi cutter Housing & 3" Circular Cutter 8mm
② Body & Safety Cover
③ Wide Handle
④ 4" Safety Cover
⑤ Drive Gear
⑥ Adapter Ring 42.50 & 44.00
⑦ Torx Wrench & L Wrench
⑧ Spanner
⑨ Timing Belt 200, 270, 348 XL
⑩ 4" Circular Cutter 8mm
⑪ 2 Extension Tools (270, 348 mm)
TECHNICAL SPECIFICATIONS
• Model : MP21-3-M
• Max. Blade Diameter : 100 mm @ 4” Blades
• Max. Carving Depth : 35 mm @ 4” Blades
• Max. RPM : 15,000 rpm @ extension spindle
• Power : 630 ~750 Watt
• Disc Bore Size: 16.03 mm
• Weight : 0.8 Kg (without angle grinder)
• Overall Length : 200, 270, 348 mm
• Working Width : 35 mm @ 4” Blades
• Blade Width : 8 mm
• Number Of Teeth : 4 EA @ 4” Blades
• Max. Blade Diameter : 100 mm @ 4” Blades
• Max. Carving Depth : 35 mm @ 4” Blades
• Max. RPM : 15,000 rpm @ extension spindle
• Power : 630 ~750 Watt
• Disc Bore Size: 16.03 mm
• Weight : 0.8 Kg (without angle grinder)
• Overall Length : 200, 270, 348 mm
• Working Width : 35 mm @ 4” Blades
• Blade Width : 8 mm
• Number Of Teeth : 4 EA @ 4” Blades
Angle Grinder : Spindle Size & Model
Angle grinder is not included.
Please check your "Spindle size" and "angle grinder".
M10 : Fit to Bosch, Makita
M14 : Fit to Bosch : 1375A, GWS8-45, GWS9-45, GWS18V-45
Makita : GA4030K, GA4030, GA4530K, GA4530, GA4534, GA4530X, 9557NB, 9556NB, 9558PB, 9557PB, 9565PCV, GA4542C
XAG042Z, XAG09Z, XAG11Z, XAG16Z, XAG20Z, XAG17ZU, XAG21ZU.
Dewalt : DCG405B, DWE4011, DWE4012, DWE4120, DWE4120N
Milwaukee : 2783-20(22,22HD), 2781-20(21,22,22HD), 2980-20(21-22), 2981-20(21,22)
5/8"-11 : Fit to Bosch : 1375A, GWS8-45, GWS9-45, GWS18V-45
Makita : GA4030K, GA4030, GA4530K, GA4530, GA4534, GA4530X, 9557NB, 9556NB, 9558PB, 9557PB, 9565PCV, GA4542C
XAG042Z, XAG09Z, XAG11Z, XAG16Z, XAG20Z, XAG17ZU, XAG21ZU.
Dewalt : DCG405B, DWE4011, DWE4012, DWE4120, DWE4120N
Milwaukee : 2783-20(22,22HD), 2781-20(21,22,22HD), 2980-20(21-22), 2981-20(21,22)
Please check your "Spindle size" and "angle grinder".
M10 : Fit to Bosch, Makita
M14 : Fit to Bosch : 1375A, GWS8-45, GWS9-45, GWS18V-45
Makita : GA4030K, GA4030, GA4530K, GA4530, GA4534, GA4530X, 9557NB, 9556NB, 9558PB, 9557PB, 9565PCV, GA4542C
XAG042Z, XAG09Z, XAG11Z, XAG16Z, XAG20Z, XAG17ZU, XAG21ZU.
Dewalt : DCG405B, DWE4011, DWE4012, DWE4120, DWE4120N
Milwaukee : 2783-20(22,22HD), 2781-20(21,22,22HD), 2980-20(21-22), 2981-20(21,22)
5/8"-11 : Fit to Bosch : 1375A, GWS8-45, GWS9-45, GWS18V-45
Makita : GA4030K, GA4030, GA4530K, GA4530, GA4534, GA4530X, 9557NB, 9556NB, 9558PB, 9557PB, 9565PCV, GA4542C
XAG042Z, XAG09Z, XAG11Z, XAG16Z, XAG20Z, XAG17ZU, XAG21ZU.
Dewalt : DCG405B, DWE4011, DWE4012, DWE4120, DWE4120N
Milwaukee : 2783-20(22,22HD), 2781-20(21,22,22HD), 2980-20(21-22), 2981-20(21,22)
Usage and Safety Precautions
- Please read and follow all safety instructions carefully. Please keep the manual for future reference.
- When operating, always wear safety equipment such as face masks and safety goggles.
- Always secure the workpiece securely when working.
- Make sure that the grinder switch is off before plugging in the power cord.
- Be careful not to touch the cutter blade. Serious injury may result.
- Always operate the tool with both hands firmly gripped, and never leave the tool with rotation.
- When using the tool, always use 220V without speed adjustment so that the speed does not fall below 11000RPM.
- After operation, turn off the switch and set it down when The remaining rotation stops completely.
- Please be sure to use it carefully because it may cause the rotation reaction(kick back) depending on the direction of rotation.
- Please remove the stone, sand and other material beforehand to use. If not, you may get blade damage.
- Please read and follow all safety instructions carefully. Please keep the manual for future reference.
- When operating, always wear safety equipment such as face masks and safety goggles.
- Always secure the workpiece securely when working.
- Make sure that the grinder switch is off before plugging in the power cord.
- Be careful not to touch the cutter blade. Serious injury may result.
- Always operate the tool with both hands firmly gripped, and never leave the tool with rotation.
- When using the tool, always use 220V without speed adjustment so that the speed does not fall below 11000RPM.
- After operation, turn off the switch and set it down when The remaining rotation stops completely.
- Please be sure to use it carefully because it may cause the rotation reaction(kick back) depending on the direction of rotation.
- Please remove the stone, sand and other material beforehand to use. If not, you may get blade damage.
Maintenance and inspection
- Inspect and tighten the bolts of each part before operation.
- After working, please keep clean so that there is no foreign matter such as dust, sawdust and rosin.
- If the cutter blade or belt is worn out, replace it with a new one.
Quality display
- Manufacturer : MANPA corporation.
- Country of manufacture : Made in the Republic of korea.
- Address : Manpa corporation, 700-20 manseo-ro, Yangseong-myeon, Anseong-si, Gyeonggi-do
